Description
Beyond the Size!
This wood fireplace offers peace of mind due to the combination of energy efficiency and clean heating. A simple solution; its clean design suits any type of decor.Large fireplace. Behind its large glass door, the 4.28 cubic foot combustion chamber can hold an impressive 60 lbs of wood.
Low emissions. This energy efficient fireplace complies with the EPA’s clean-air standards (only 1.6 g/hr of emissions) in particular through the intelligent air control mechanism is a patented design that optimizes combustion quality.
High efficiency. The Horizon fireplace is capable of heating large spaces and burns for 11 hours.
-
Specifications
Recommended chimney diameter
8"
Height X Width X Depth - Overall
43 3/8" X 50 3/4" X 31 3/4"
Maximum log length
25"
Weight
550 lb (250 kg)
Recommended heating area (sq.ft.)
1,000 - 2,800
Maximum burn time
10 h
Firebox volume (cu. ft.)
4.28
Blower Included
Yes
Fuel type
Dry cordwood
Maximum heat output
95,000 BTU/h (27.8 kW)
GENERAL FEATURES
Stainless-steel secondary-air system improving gas combustion
Yes
Burn rate
<1.5 kg/h (<3.3 lb/h)
Automatic or manual adjustment of combustion air supply
Yes
Maximum log length
25"
Log positioning
Over width
Chimney diameter
8"
Minimum chimney height (feet)
15'
Baffle type
C-Cast
Approved for a mobile home installation
No
Shipping Weight
550 lb (250 kg)
Door type
Double, glass with cast iron frame
Glass type
Ceramic glass
Glass surface – dimensions (Width X Height)
29 3/4" X 13 1/2"
Glass air-wash system
Yes
Premium quality blower included (CFM)
176
Overall dimension (Height)
43 3/8"
Overall dimension (Width)
50 3/4"
Overall dimension (Depth)
31 3/4"
Door opening – dimension (Height)
12 3/4"
Door opening - dimension (Width)
33"
Firebox – dimension (Height)
17"
Firebox – dimension (Width)
25 3/8"
Firebox – dimension (Depth)
17 7/8"
Moulded refractory bricks
Yes
Centre line of flue outlet to the side
25 3/8"
Centre line of flue outlet to the back
11 7/8"
USA standard (emissions)
EPA / ASTM WK47329
Canadian Standard (emissions)
CSA B415.1-10
USA standard (safety)
UL 127
Canadian standard (safety)
ULC-S610
Tested and listed as per applicable standards
By an accredited laboratory (CAN/USA)
Warranty
Limited lifetime
Combustible top shelf to unit
N.A.
