Description
Fuel type :
Dry cordwood
Recommended heating area-ft² :
750 - 2,200
Overall firebox volume :
2.5
EPA loading volume-ft³ :
1.69
Maximum burn time :
8 h
Maximum heat output (dry cordwood) :
80,000 BTU/h (23.4 kW)
14,200 BTU/h (4.16 kW) to 48,200 BTU/h (14.13 kW)
Average overall efficiency (EPA cribs/Douglas fir) :
N.A. (HHV)
N.A. (LHV)
Average overall efficiency (dry cordwood) :
68 % (HHV)
73 % (LHV)
Optimum efficiency :
74 %
Average particulate emissions rate :
1.14 g/h
Average CO :
53 g/h
GENERAL FEATURES
Combustion technology
Non-catalytic
High-efficiency certified appliance
Yes, EPA 2020 approved
Maximum log length
20"
Log positioning
Over width
Chimney diameter
6"
Flue outlet diameter
6"
Type of chimney
Liner - ULC-S635, CAN/ULC-S640, UL1777
Minimum chimney height (feet)
15'
Baffle type
C-Cast
Approved for a mobile home installation
No
Shipping Weight
535 lb (243kg)
Door type
Single, glass with cast iron frame
Glass type
Ceramic glass
Glass surface – dimensions (Width X Height)
24 3/8" X 12 5/8"
Glass air-wash system
Yes
Premium quality blower included (CFM)
176
Overall dimension (Height)
30 1/8"
Overall dimension (Width)
43 5/8"
Overall dimension (Depth)
27 1/4"
Door opening – dimension (Height)
10 1/2"
Door opening - dimension (Width)
25 3/8"
Firebox – dimension (Height)
12 3/8"
Firebox – dimension (Width)
22 5/8"
Firebox – dimension (Depth)
12 7/8"
Moulded refractory bricks
Yes
Stainless-steel secondary-air system improving gas combustion
Yes
Adjustable threaded legs
Yes
Fireplace opening – minimum (Height)
27 1/8"
Fireplace opening – minimum (Width)
31 3/4"
Fireplace opening – minimum (Depth)
22 1/8"
USA standard (emissions)
EPA
Canadian Standard (emissions)
CSA B415.1-10
USA standard (safety)
UL 1482, UL 737
Canadian standard (safety)
ULC S628
Tested and listed as per applicable standards
By an accredited laboratory (CAN/USA)
Warranty
Limited lifetime
Minimum clearances to combustibles*
(Data expressed in inches. 1 inch = 25.4 mm)
Canada
United-States
Clearance – top (measured from the platform on which the appliance is installed)**
84"
84"
Clearance – combustible side mantle to unit
9 1/2"
9 1/2"
Clearance – combustible top mantle to unit
12"
12"
Clearance – combustible side wall to unit
19"
19"
Clearance – minimum floor protection in front of the appliance
18"
16"
* The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or web sites).
** Some appliances have been tested with a low ceiling. Before setting up your unit, refer to the installation manual.
-
