FP7CB ANTOINETTE - WOOD FIREPLACE
A true delight for lovers of pure lines with its large glass surface and its sleek faceplate, the Antoinette fireplace will enhance any decor while respecting the style of your room. The authentic guillotine door, developed by Valcourt, slides effortlessly to allow you to easily feed the fire, just like its spark fire screen also equipped with a guillotine mechanism.
The Antoinette qualifies for phase II of the EPA's voluntary program which aims to reduce emissions from decorative wood fireplaces, making it up to 70% cleaner than unqualified models!
Features
Fuel type
Dry cordwood
Recommended heating area-ft²
<1,000
Overall firebox volume-ft³
5.3
Average particulate emissions rate
4.2 g/kg
Burn rate
>5 kg/h (>11 lb/h)
High-efficiency certified appliance
Low Mass
Maximum log length
18''
Log positioning
Over width
Chimney diameter
8"
Type of chimney
CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height (feet)
15'
Approved for a mobile home installation
No
Shipping Weight
523 lb (238 kg)
Door type
Guillotine, glass with steel frame
Glass type
Ceramic glass
Glass surface – dimensions (Width X Height)
29 3/4'' X 19 1/2''
Overall dimension (Height)
64 1/8''
Overall dimension (Width)
48 7/8''
Overall dimension (Depth)
30 3/4''
Door opening – dimension (Height)
21 1/4''
Door opening - dimension (Width)
33''
Firebox – dimension (Height)
21 3/4''
Firebox – dimension (Width)
24 1/4''
Firebox – dimension (Depth)
11 1/2''
Moulded refractory bricks
Yes
Cast iron andirons
Yes
USA standard (emissions)
ASTM 2515 / ASTM 2558
USA standard (safety)
UL 127
Canadian standard (safety)
ULC-S610
Warranty
Limited lifetime
-
Specifications
