Description
The Lumis 16 fireplace insert combines cutting-edge engineering with timeless elegance to create an exceptional home-heating experience. Designed for high-efficiency performance, Lumis features a patented automatic air-control systemthat adjusts airflow in real time to deliver steady, clean combustion and consistent heat output with ease.
Its dual-blower system maximizes heat distribution, efficiently warming larger spaces while minimizing energy loss. The reversible cast-iron panels provide remarkable durability and a refined aesthetic, while the innovative baffle systemenhances heat retention for longer-lasting comfort and reduced emissions.
Perfect for homeowners who value quality, design, and performance, the Lumis 16 redefines what a premium fireplace insert can achieve. Available at Le Groupe Belleflamme, this modern masterpiece brings efficiency, style, and warmthtogether—setting a new benchmark in fireplace technology.
PATENTED AUTOMATIC AIR CONTROL
This patented, user-friendly mechanism automatically reduces the amount of combustion air introduced during ignition to the desired burn rate setting. The result is a beautifully consistent fire burning to its full capacity.
FACEPLATE OVERLAY
A 12 gauge thick faceplate is offered optionally to aesthetically conceal the opening between the existing masonry fireplace and the surround of the unit. It can easily be trimmed all depending on the installation and the dimensions.
DUAL BLOWER SYSTEM (60 CFM)
Pre-assembled on the circulating chamber, the blowers help circulate the warm air into the room. As the combustion progresses, the blowers automatically activate with the heat and can be set using the variable speed control.
REVERSIBLE CAST-IRON PANELS
Crafted with care, our heavy-duty cast iron panels are stamped with a brick pattern on one side and a flowing contemporary design on the other. These reversible panels provide a versatile design that is as beautiful as it is functional.
CHIMNEY SWEEPING CAP
Located on the baffle, this convenient feature allows the chimney to be easily accessed for cleaning, without requiring the removal of any components.
INNOVATIVE BAFFLE DESIGN
Our products have a unique design that allows secondary air to enter through a perforated baffle offering an unimpeded viewing area to the fire all while increasing the efficiency and prolonging the combustion.
-
Specifications
Heat Capacity:
Up to 750 square feet
Maximum Heat Output:
Up to 60,000 BTUs
Heating time:
3 to 6 hours
EPA Firebox Size:
1.4 cubic feet
Chimney Liner:
5 inch
Log Size:
Up to 16”
Emissions:
1 g/hr EPA 2020 Certified
Glass Dimensions:
15” X 10”
