Description
The new standard lowering the fine particulate emission threshold will be conquered by the recent certification of the Osburn 2000 wood burning stove. This revamped version now offers a particulate emissions rate of 2.3 g/h, a maximum heat output of 75,000 BTU/h and 79% optimum efficiency. This insert still has a 2.4 ft3combustion chamber and a 144-CFM variable speed fan that is strategically positioned to redistribute heat throughout the room.
Designed to receive an optional faceplate that can cover a masonry hearth up to 32 inches (81 cm) high and 50 inches (127 cm) wide. A steel door overlay is available in black or brushed nickel as well as faceplate trims. Look no further, treat yourself to Osburn's legendary quality.
FEATURES
Combustion technology
Non-catalytic
High-efficiency certified appliance
Yes, EPA 2020 approved
Maximum log length
20"
Log positioning
Loading over width
Chimney diameter
6"
Type of chimney
Liner - ULC-S635, CAN/ULC-S640, UL1777
Minimum chimney height (feet)
12'
Baffle type
C-Cast or equivalent
Approved for a mobile home installation
No
Shipping Weight
434 lb (197 kg)
Door type
Single, glass with cast iron frame
Glass type
Ceramic glass
Glass surface – dimensions (Width X Height)
17 1/8" X 10 1/4"
Glass air-wash system
Yes
Premium quality blower included (CFM)
144
Overall dimension (Height)
23 1/8"
Overall dimension (Width)
28 3/8"
Overall dimension (Depth)
26 3/8"
Door opening – dimension (Height)
9"
Door opening - dimension (Width)
17 1/2"
Firebox – dimension (Height)
11 7/8"
Firebox – dimension (Width)
21"
Firebox – dimension (Depth)
16 3/4"
Firebox lined with refractory bricks for better heat distribution
Yes
Stainless-steel secondary-air system improving gas combustion
Yes
Adjustable threaded legs
Yes
Steel thickness – body
3/16"
Steel thickness – top
5/16"
Fireplace opening – minimum (Height)
23 3/8"
Fireplace opening – minimum (Width)
28 7/8"
Fireplace opening – minimum (Depth)
15 3/4"
USA standard (emissions)
Comply with EPA 2020
Canadian Standard (emissions)
CSA B415.1-10
USA standard (safety)
UL 1482, UL 737
Canadian standard (safety)
ULC S628
Tested and listed as per applicable standards
By an accredited laboratory (CAN/USA)
Warranty
Limited lifetime
-
Specifications
Fuel type :
Dry cordwood (16" recommended)
Recommended heating area-ft² :
500 - 2,100
Overall firebox volume-ft³ :
2.4
EPA loading volume-ft³ :
1.95
Maximum burn time :
8 h
Maximum heat output-dry cordwood :
75,000 BTU/h (22.0 kW)
Overall heat output rate < :
14,200 BTU/h (4.16 kW) to 44,500 BTU/h (13.04 kW)
Average overall efficiency (dry cordwood) :
72 % (HHV)
77 % (LHV)
Optimum overall efficiency :
79 %
Optimum heat transfer efficiency :
76 %
Average particulate emissions rate :
2.3 g/h
Average CO :
69 g/h
