Description
With its 2.4 cubic foot firebox, the Osburn 2000 insert offers an alternative to the people who love its freestanding counterpart. The two models share the same high quality combustion properties and many of the same features.
This appliance comes with a standard high-power, heat-activated 120 CFM fan strategically positioned to redistribute the heat from the firebox into the room.
The 2000 model is designed to receive an optional faceplate that can cover a masonry hearth up to 32 inches (81 cm) high and 50 inches (127 cm) wide. The door overlay is available in black or brushed nickel plated finishes and the faceplate trims too.
-
Specifications
Height X Width X Depth - Overall
23 1/8" X 28 3/8" X 26 1/2"
Maximum log length
20"
Fireplace opening - minimum (Height X Width X Depth)
23 3/8" X 28 7/8" X 15 3/4"
Weight
421 lb (191 kg)
Firebox volume (cu. ft.)
2.4
Recommended heating area (sq.ft.)
500 - 2,100
Recommended chimney diameter
6"
Maximum burn time
6 h
Blower Included
Yes
Fuel Type
Dry cordwood
Maximum heat output
75,000 BTU/h (22.0 kW)
GENERAL FEATURES
Adjustable threaded legs Yes Stainless-steel secondary-air system improving gas combustion Yes Automatic or manual adjustment of combustion air supply Yes Maximum log length 20" Log positioning Over width Chimney diameter 6" Baffle type C-Cast Approved for a mobile home installation No Shipping Weight 421 lb (191 kg) Door type Single, glass with cast iron frame Glass type Ceramic glass Glass surface – dimensions (Width X Height) 17 1/4" x 9 1/2" Glass air-wash system Yes Premium quality blower included (CFM) 120 Overall dimension (Height) 23 1/8" Overall dimension (Width) 28 3/8" Overall dimension (Depth) 26 1/2" Door opening – dimension (Height) 9" Door opening - dimension (Width) 17 1/2" Firebox – dimension (Height) 11 7/8" Firebox – dimension (Width) 21" Firebox – dimension (Depth) 16 3/4" Firebox lined with refractory bricks for better heat distribution Yes Steel thickness – body 3/16" Steel thickness – top 5/16" Centre line of flue outlet to the side 13 1/2" Centre line of flue outlet to the back 6 7/8" Fireplace opening – minimum (Height) 23 3/8" Fireplace opening – minimum (Width) 28 7/8" Fireplace opening – minimum (Depth) 15 3/4" USA standard (emissions) EPA Method 28 Canadian Standard (emissions) CSA B415.1-10 USA standard (safety) UL 1482, UL 737 Canadian standard (safety) ULC S628 Tested and listed as per applicable standards By an accredited laboratory (CAN/USA) Warranty Limited
- Videos
With its 2.4 cubic foot firebox, the Osburn 2000 insert offers an alternative to the people who love its freestanding counterpart. The two models share the same high quality combustion properties and many of the same features.
This appliance comes with a standard high-power, heat-activated 120 CFM fan strategically positioned to redistribute the heat from the firebox into the room.
The 2000 model is designed to receive an optional faceplate that can cover a masonry hearth up to 32 inches (81 cm) high and 50 inches (127 cm) wide. The door overlay is available in black or brushed nickel plated finishes and the faceplate trims too.
|
Height X Width X Depth - Overall |
23 1/8" X 28 3/8" X 26 1/2" |
|
Maximum log length |
20" |
|
Fireplace opening - minimum (Height X Width X Depth) |
23 3/8" X 28 7/8" X 15 3/4" |
|
Weight |
421 lb (191 kg) |
|
Firebox volume (cu. ft.) |
2.4 |
|
Recommended heating area (sq.ft.) |
500 - 2,100 |
|
Recommended chimney diameter |
6" |
|
Maximum burn time |
6 h |
|
Blower Included |
Yes |
|
Fuel Type |
Dry cordwood |
|
Maximum heat output |
75,000 BTU/h (22.0 kW) |
GENERAL FEATURES
| Adjustable threaded legs | Yes |
| Stainless-steel secondary-air system improving gas combustion | Yes |
| Automatic or manual adjustment of combustion air supply | Yes |
| Maximum log length | 20" |
| Log positioning | Over width |
| Chimney diameter | 6" |
| Baffle type | C-Cast |
| Approved for a mobile home installation | No |
| Shipping Weight | 421 lb (191 kg) |
| Door type | Single, glass with cast iron frame |
| Glass type | Ceramic glass |
| Glass surface – dimensions (Width X Height) | 17 1/4" x 9 1/2" |
| Glass air-wash system | Yes |
| Premium quality blower included (CFM) | 120 |
| Overall dimension (Height) | 23 1/8" |
| Overall dimension (Width) | 28 3/8" |
| Overall dimension (Depth) | 26 1/2" |
| Door opening – dimension (Height) | 9" |
| Door opening - dimension (Width) | 17 1/2" |
| Firebox – dimension (Height) | 11 7/8" |
| Firebox – dimension (Width) | 21" |
| Firebox – dimension (Depth) | 16 3/4" |
| Firebox lined with refractory bricks for better heat distribution | Yes |
| Steel thickness – body | 3/16" |
| Steel thickness – top | 5/16" |
| Centre line of flue outlet to the side | 13 1/2" |
| Centre line of flue outlet to the back | 6 7/8" |
| Fireplace opening – minimum (Height) | 23 3/8" |
| Fireplace opening – minimum (Width) | 28 7/8" |
| Fireplace opening – minimum (Depth) | 15 3/4" |
| USA standard (emissions) | EPA Method 28 |
| Canadian Standard (emissions) | CSA B415.1-10 |
| USA standard (safety) | UL 1482, UL 737 |
| Canadian standard (safety) | ULC S628 |
| Tested and listed as per applicable standards | By an accredited laboratory (CAN/USA) |
| Warranty |
Limited |
