Description
Designed to meet the needs of smaller spaces, the Osburn 1700 combines robustness and elegance to allow you to enjoy your heating experience with confidence. This unit is equipped with high-density bricks, a stainless steel heat shield added to the C-Cast baffle, a cast iron door, a built-in ash pan, a top heat deflector that redirects heat to the front of the unit, and side panels to reduce its clearances.
Choose your favorite version by customizing the unit to suit your style: refined door overlays, new leg designs, glass ash lip; significant innovations for the most seasoned experts.
FEATURES
Combustion technology
Non-catalytic
High-efficiency certified appliance
Yes, EPA 2020 approved
Maximum log length
18"
Log positioning
Loading over width
Chimney diameter
6"
Flue outlet diameter
6"
Type of chimney
CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height (feet)
15'
Baffle type
C-Cast or equivalent
Approved for an alcove installation
Yes
Approved for a mobile home installation
Yes
Shipping Weight
336 lb (153 kg)
Door type
Single, glass with cast iron frame
Glass type
Ceramic glass
Glass surface – dimensions (Width X Height)
15 3/4" x 9 3/8"
Glass air-wash system
Yes
Overall dimension (Height)
30 3/8"
Overall dimension (Width)
24 7/8"
Overall dimension (Depth)
23 1/4"
Door opening – dimension (Height)
8 3/4"
Door opening - dimension (Width)
17 1/4"
Firebox – dimension (Height)
11 7/8"
Firebox – dimension (Width)
19 5/8"
Firebox – dimension (Depth)
13 1/2"
Firebox lined with refractory bricks for better heat distribution
Yes
Stainless-steel secondary-air system improving gas combustion
Yes
Model
Legs or pedestal
Steel thickness – body
3/16"
Steel thickness – top
5/16"
USA standard (emissions)
EPA
Canadian Standard (emissions)
CSA B415.1-10
USA standard (safety)
UL 1482, UL 737
Canadian standard (safety)
ULC S627
Tested and listed as per applicable standards
By an accredited laboratory (CAN/USA)
Warranty
Limited lifetime
-
Specifications
Fuel type :
Dry cordwood (16" recommended)
Recommended heating area-ft² :
500 - 1,800
Overall firebox volume-ft³ :
1.86
EPA loading volume-ft³ :
1.44
Maximum burn time :
7 h
Maximum heat output-dry cordwood :
65,000 BTU/h (19 kW)
Overall heat output rate < :
9,800 BTU/h (2.87 kW) to 52,200 BTU/h (15.3 kW)
Average overall efficiency (dry cordwood) :
68 % (HHV)
73 % (LHV)
Optimum overall efficiency :
76 %
Optimum heat transfer efficiency :
75 %
Average particulate emissions rate :
2.4 g/h
Average CO :
103 g/h
